using System;
using System.Windows.Forms;
namespace NumericalDifferentiation
{
public partial class Form1 : Form
{
public Form1()
{
InitializeComponent();
comboBox1.SelectedIndex = 0;
}
private double F1(double x)
{
return x * (x * (x - 2) + 4) - 1;
}
private double F2(double x)
{
return x * Math.Exp(-x) + 1;
}
private double F3(double x)
{
return x * x * Math.Sin(x) + 1;
}
private double DF1(double x)
{
return 3 * x * x - 4 * x + 4;
}
private double DF2(double x)
{
return Math.Exp(-x) - x * Math.Exp(-x);
}
private double DF3(double x)
{
return 2 * x * Math.Sin(x) + x * x * Math.Cos(x);
}
private double DDF1(double x)
{
return 6 * x - 4;
}
private double DDF2(double x)
{
return -2 * Math.Exp(-x) + x * Math.Exp(-x);
}
private double DDF3(double x)
{
return
2 * Math.Sin(x) + 2 * x * Math.Cos(x) +
2 * x * Math.Cos(x) - x * x * Math.Sin(x);
}
private void button1_Click(object sender, EventArgs e)
{
double a = (double)numericUpDown1.Value;
double b = (double)numericUpDown2.Value;
int n = (int)numericUpDown3.Value;
double deriv1c, deriv1f;
double deriv2c, deriv2f;
double x = a, y, u, v;
double error1c, error1f, error2c, error2f;
double h = (b - a) / n;
if (comboBox1.SelectedIndex == 0)
textBox1.Text += "x\t f'(x) e f'(x) 1 f'(x) 2 " +
"error1 error2 f''(x)e f''(x)1 f''(x)2 " +
"error1 error2\r\n";
else if (comboBox1.SelectedIndex == 1)
textBox1.Text += "x\t g'(x) e g'(x) 1 g'(x) 2 " +
"error1 error2 g''(x)e g''(x)1 g''(x)2 " +
"error1 error2\r\n";
else if (comboBox1.SelectedIndex == 2)
textBox1.Text += "x\t h'(x) e h'(x) 1 h'(x) 2 " +
"error1 error2 h''(x)e h''(x)1 h''(x)2 " +
"error1 error2\r\n";
while (x <= b)
{
switch (comboBox1.SelectedIndex)
{
case 0:
y = F1(x);
u = DF1(x);
v = DDF1(x);
deriv1c = Differentiation.Derivative1sc(x, h, F1);
deriv1f = Differentiation.Derivative1sf(x, h, F1);
deriv2c = Differentiation.Derivative2sc(x, h, F1);
deriv2f = Differentiation.Derivative2sf(x, h, F1);
error1c = Math.Abs(deriv1c - u);
error1f = Math.Abs(deriv1f - u);
error2c = Math.Abs(deriv2c - v);
error2f = Math.Abs(deriv2f - v);
textBox1.Text +=
x.ToString("F5").PadLeft(8) + " " +
u.ToString("F5").PadLeft(8) + " " +
deriv1c.ToString("F5").PadLeft(8) + " " +
deriv1f.ToString("F5").PadLeft(8) + " " +
error1c.ToString("F5").PadLeft(8) + " " +
error1f.ToString("F5").PadLeft(8) + " " +
v.ToString("F5").PadLeft(8) + " " +
deriv2c.ToString("F5").PadLeft(8) + " " +
deriv2f.ToString("F5").PadLeft(8) + " " +
error2c.ToString("F5").PadLeft(8) + " " +
error2f.ToString("F5").PadLeft(8) + "\r\n";
break;
case 1:
y = F2(x);
u = DF2(x);
v = DDF2(x);
deriv1c = Differentiation.Derivative1sc(x, h, F2);
deriv1f = Differentiation.Derivative1sf(x, h, F2);
deriv2c = Differentiation.Derivative2sc(x, h, F2);
deriv2f = Differentiation.Derivative2sf(x, h, F2);
error1c = Math.Abs(deriv1c - u);
error1f = Math.Abs(deriv1f - u);
error2c = Math.Abs(deriv2c - v);
error2f = Math.Abs(deriv2f - v);
textBox1.Text +=
x.ToString("F5").PadLeft(8) + " " +
u.ToString("F5").PadLeft(8) + " " +
deriv1c.ToString("F5").PadLeft(8) + " " +
deriv1f.ToString("F5").PadLeft(8) + " " +
error1c.ToString("F5").PadLeft(8) + " " +
error1f.ToString("F5").PadLeft(8) + " " +
v.ToString("F5").PadLeft(8) + " " +
deriv2c.ToString("F5").PadLeft(8) + " " +
deriv2f.ToString("F5").PadLeft(8) + " " +
error2c.ToString("F5").PadLeft(8) + " " +
error2f.ToString("F5").PadLeft(8) + "\r\n";
break;
case 2:
y = F3(x);
u = DF3(x);
v = DDF3(x);
deriv1c = Differentiation.Derivative1sc(x, h, F3);
deriv1f = Differentiation.Derivative1sf(x, h, F3);
deriv2c = Differentiation.Derivative2sc(x, h, F3);
deriv2f = Differentiation.Derivative2sf(x, h, F3);
error1c = Math.Abs(deriv1c - u);
error1f = Math.Abs(deriv1f - u);
error2c = Math.Abs(deriv2c - v);
error2f = Math.Abs(deriv2f - v);
textBox1.Text +=
x.ToString("F5").PadLeft(8) + " " +
u.ToString("F5").PadLeft(8) + " " +
deriv1c.ToString("F5").PadLeft(8) + " " +
deriv1f.ToString("F5").PadLeft(8) + " " +
error1c.ToString("F5").PadLeft(8) + " " +
error1f.ToString("F5").PadLeft(8) + " " +
v.ToString("F5").PadLeft(8) + " " +
deriv2c.ToString("F5").PadLeft(8) + " " +
deriv2f.ToString("F5").PadLeft(8) + " " +
error2c.ToString("F5").PadLeft(8) + " " +
error2f.ToString("F5").PadLeft(8) + "\r\n";
break;
default:
break;
}
x += h;
}
textBox1.Text += comboBox1.SelectedItem;
}
private void button2_Click(object sender, EventArgs e)
{
textBox1.Text = string.Empty;
}
}
}
// Derivative formulas translated from FORTRAN 77
// source code found in "Elementary Numerical Analysis:
// An Algorithmic Approach" by S. D. Conte and Carl de
// Boor. Translator: James Pate Williams, Jr. (c)
// August 18 - 19, 2023
using System;
namespace NumericalDifferentiation
{
// Numerically compute first and second
// ordinary derivatives
class Differentiation
{
static public double Derivative1sc(
double a, double h, Func<double, double> f)
{
return (f(a + h) - f(a - h)) / (h + h);
}
static public double Derivative1sf(
double a, double h, Func<double, double> f)
{
return (-3.0 * f(a) + 4.0 * f(a + h) - f(a + h + h)) / (h + h);
}
static public double Derivative2sc(
double a, double h, Func<double, double> f)
{
return (f(a - h) - 2.0 * f(a) + f(a + h)) / (h + h);
}
static public double Derivative2sf(
double a, double h, Func<double, double> f)
{
return (f(a) - 2.0 * f(a + h) + f(a + h + h)) / (h + h);
}
}
}
